Купить Brazil HT46F47E 18SOP-electric control A/D Flash MCUeletric motor subsystems SCM | Электронные компоненты и
![aeProduct.getSubject()]() | VORICE HT46F47E in A/D-new Flash MCU In 03/03/2008 ![aeProduct.getSubject()]() VORICE semiconductor after the I/O Flash MCU, and launched a/d converter-Flash MCUHT46F47E.HT46F47EThrough the ICP program memory (In-Circuit Programming) interface to MCU program memory has created a good product to burn, and burn up to 100,000 times, this feature allows customers to easily make product software updates, which can shorten the time to market for products, and to provide after-sales service. For example customers before delivery and you can burn the latest version of the program and adjust parameters, without limited burning times where product is sold, you can very easily do software upgrade offer higher added value.
HT46F47EROM for 2k*14, and EEPROM 128 bytes, RAM is 64 Bytes, I/O up to 13 ports, in addition toHT46F47EA/d resolution of 9 bits, and there are a total of 4 channels external analog signal can be used as monitoring purposes, such as different Sensor can be used in detection, such as battery voltage, current, temperature, humidity, pressure, intensity, and other functions.HT46F47EProvide PWM output also can be applied to control the temperature, speed, constant voltage, constant current control. Matching PFD (Programmable Frequency Divider) can be applied at any frequency to vocal component generates beautiful music, or carrier signal applied to infrared transfer.
This product has high noise immunity characteristic of VORICE 8-bit MCU, watchdog (Watchdog) and LVR functionality enhanced MCU crash-proof capability.HT46F47ESealed types 16NSOP, 18DIP/SOP and 20SSOP four patterns.
|
| | | Download DataSheet | | HT46F47E | | Further information | | Contact us |
|
![aeProduct.getSubject()]() |
Part No. | Internal
Clock | VDD | System
Clock | Program
Memory | Data
Memory | Data
EEPROM | I/O | RTC | A/D | Timer
Module | Comp. | R-type
LCD
(1/3 Bias) | High
Current
LED Output | Inter-
face | Stack | Package | | HT66F016 | 8MHz | 2.2V~
5.5V | 400kHz~
20MHz or
32kHz | 1Kx16 | 64x8 | 64x8 | 14 | -- | 12-bitx4 | 16-bit STMx1 | 1 | -- | -- | -- | 4 | 16DIP/NSOP/SSOP | | HT66F017 | 8MHz | 2.2V~
5.5V | 400kHz~
20MHz or
32kHz | 2Kx16 | 128x8 | 64x8 | 14 | -- | 12-bitx4 | 16-bit CTMx1
16-bit STMx1 | 1 | -- | -- | -- | 8 | 16DIP/NSOP/SSOP | | HT66F0172 | 8MHz | 2.2V~
5.5V | 400kHz~
20MHz or
32kHz | 2Kx16 | 128x8 | -- | 18 | -- | 12-bitx8 | 10-bit PTMx2 | -- | -- | -- | -- | 8 | 20 SOP/SSOP | | HT66F0174 | 64x8 | v | | HT66F0175* | 8MHz
12MHz
16MHz | 22 | 6(SCOM/
SSEG)
+14SSEG | 22 | SPI/I⊃2;C | 20/24SOP/SSOP | | HT66F018 | 8MHz
12MHz
16MHz | 2.2V~
5.5V | 400kHz~
20MHz or
32kHz | 4Kx16 | 192x8 | 64x8 | 18 | v | 12-bitx8 | 10-bit PTMx1
16-bit CTMx1
16-bit STMx1 | 1 | -- | -- | -- | 8 | 20 SOP/SSOP | | HT66F0185* | 128x8 | 26 | 6(SCOM/
SSEG)
+18SSEG | 26 | SPI/I⊃2;C,
UART | 24/28SOP/SSOP | * Under development, available in 4Q, 2014.
Note: The external reset pin is provided in HT66F016R/HT66F017R. |
Part No. | Internal
Clock | VDD | System
Clock | Program
Memory | Data
Memory | Data
EEPROM | I/O | RTC | A/D | Timer
Module | R-type
LCD | Comp. | Stack | Package | | HT66F317* | 4MHz
8MHz
12MHz | 1.8V~
5.5V | 400kHz~
20MHz or
32kHz | 2Kx16 | 128x8 | 64x8 | 18 | v | 12-bitx8 | 10-bit PTMx2 | 4SCOM | -- | 8 | 16NSOP
20/24SOP/SSOP | | HT66F318* | 4MHz
8MHz
12MHz | 1.8V~
5.5V | 400kHz~
20MHz or
32kHz | 4Kx16 | 192x8 | 64x8 | 26 | v | 12-bitx8 | 10-bit PTMx1
16-bit CTMx1
16-bit STMx1 | 4SCOM | 1 | 8 | 20/24/28SOP/SSOP | | HT66F319* | 4MHz
8MHz
12MHz | 1.8V~
5.5V | 400kHz~
20MHz or
32kHz | 8Kx16 | 256x8 | 64x8 | 26 | v | 12-bitx8 | 10-bit PTMx1
16-bit CTMx1
16-bit STMx1 | 4SCOM | 1 | 8 | 20/24/28SOP/SSOP | | * Under development, available in 4Q 2014. |
| Part No. | Internal
Clock | VDD | System
Clock | Program
Memory | Data
Memory | Data
EEPROM | I/O | RTC | A/D | Timer
Module | Comp. | Interface | Stack | Package * | | HT66F20 | 4MHz
8MHz
12MHz | 2.2V~
5.5V | 400kHz~20MHz
or 32kHz | 1Kx14 | 64x8 | 32x8 | 18 | v | 12-bit
x8 | 10-bit CTMx1,
10-bit STMx1 | 2 | SPI/I2C | 4 | 16DIP/NSOP/SSOP,
20DIP/SOP/SSOP | | HT66F20-1 | 4MHz
8MHz
12MHz | 2.2V~
5.5V | 400kHz~20MHz
or 32kHz | 1Kx16 | 64x8 | 32x8 | 18 | v | 12-bit
x8 | 10-bit CTMx1,
10-bit STMx1 | 2 | SPI/I2C | 4 | 16DIP/NSOP/SSOP,
20DIP/SOP/SSOP | HT66F30 | 4MHz
8MHz
12MHz | 2.2V~
5.5V | 400kHz~20MHz
or 32kHz | 2Kx14 | 96x8 | 64x8 | 22 | v | 12-bit
x8 | 10-bit CTMx1,
10-bit ETMx1 | 2 | SPI/I2C | 4 | 16DIP/NSOP/SSOP
20DIP/SOP/SSOP
24SKDIP/SOP/SSOP | | HT66FU30 | UART | | HT66FB30 | USB | HT66F30-1 | 4MHz
8MHz
12MHz | 2.2V~
5.5V | 400kHz~20MHz
or 32kHz | 2Kx16 | 96x8 | 64x8 | 22 | v | 12-bit
x8 | 10-bit CTMx1,
10-bit ETMx1 | 2 | SPI/I2C | 4 | 16DIP/NSOP/SSOP
20DIP/SOP/SSOP
24SKDIP/SOP/SSOP | | HT66F40 | 4MHz
8MHz
12MHz | 2.2V~
5.5V | 400kHz~20MHz
or 32kHz | 4Kx15 | 192x8 | 128x8 | 42 | v | 12-bit
x8 | 10-bit CTMx1,
10-bit ETMx1,
16-bit STMx1 | 2 | SPI/I2C | 8 | 24SKDIP/SOP/SSOP
28SKDIP/SOP/SSOP
32/40QFN, 44LQFP
48QFN/SSOP | | HT66FU40 | UART | | HT66FB40 | USB | HT66F50 | 4MHz
8MHz
12MHz | 2.2V~
5.5V | 400kHz~20MHz
or 32kHz | 8Kx16 | 384x8 | 256x8 | 42 | v | 12-bit
x8 | 10-bit CTMx2,
10-bit ETMx1,
16-bit STMx1 | 2 | SPI/I2C | 8 | 28SKDIP/SOP/SSOP
40QFN, 44LQFP
48QFN/SSOP | | HT66FU50 | UART | | HT66FB50 | USB | HT66F60 | 4MHz
8MHz
12MHz | 2.2V~
5.5V | 400kHz~20MHz
or 32kHz | 12Kx16 | 576x8 | 256x8 | 50 | v | 12-bit
x12 | 10-bit CTMx2,
10-bit ETMx1,
16-bit STMx1 | 2 | SPI/I2C | 12 | 28SOP, 40QFN, 44LQFP
48SSOP/LQFP/QFN | | HT66FU60 | UART | 40QFN, 44LQFP
48SSOP/LQFP/QFN | | HT66FB60 | USB | HT66F60A | 8MHz | 2.2V~
5.5V | 400kHz~20MHz
or 32kHz | 16Kx16 | 1024x8 | 128x8 | 61 | v | 12-bit
x12 | 10-bit CTMx2,
10-bit ETMx1,
16-bit STMx3 | 2 | SPI/I2C | 16 | 48/64LQFP | HT66F70A | 8MHz | 2.2V~
5.5V | 400kHz~20MHz
or 32kHz | 32Kx16 | 2048x8 | 128x8 | 61 | v | 12-bit
x12 | 10-bit CTMx2,
10-bit ETMx1,
16-bit STMx3 | 2 | SPI/I2C | 16 | 48/64LQFP | | Note: Part number which include a "U" have an internal UART function; part numbers which include a "B" have a USB interface. All devices include a fully integrated RC system oscillator. Four I/O lines each device can be configured as software LCD COM driver pins. "*" As not all package types are available for the HT66FUx0 and HT66FBx0 devices, consult the datasheet for exact package details. |
Part No. | VDD | System
Clock | Program
Memory | Data
Memory | Data
EEPROM | I/O | 8-bit
Timer | A/D | PWM | PFD | Stack | Package | | HT46F46E | 2.2V~5.5V | 400kHz~
12MHz | 1Kx14 | 64x8 | 128x8 | 13 | 1 | 8-bitx4 | 8-bitx1 | v | 4 | 16NSOP,
18DIP/SOP | | HT46F47E | 2.2V~5.5V | 400kHz~
12MHz | 2Kx14 | 64x8 | 128x8 | 13 | 1 | 9-bitx4 | 8-bitx1 | v | 6 | 16NSOP,
18DIP/SOP, 20SSOP | | HT46F48E | 2.2V~5.5V | 400kHz~
12MHz | 2Kx14 | 88x8 | 128x8 | 19 | 1 | 9-bitx4 | 8-bitx1 | v | 6 | 24SKDIP/SOP/SSOP | | HT46F49E | 2.2V~5.5V | 400kHz~
12MHz | 4Kx15 | 128x8 | 256x8 | 23 | 1 | 9-bitx4 | 8-bitx2 | v | 6 | 24SKDIP/SOP/SSOP,
28SKDIP/SOP/SSOP |
|
![aeProduct.getSubject()]() |
HT46F46E/HT46F47E/HT46F48E/HT46F49E -- Cost-Effective A/D Flash Type 8-Bit MCU with EEPROM
(HT46F46E Restricted product announcement: 2014/04/28 effective date: 2014/07/28) Overview Economy of A/D is the built-in EEPROM 8-bit FLASH type high performance RISC MCU, specially designed for products requiring a/d conversion, such as sensor signal input. All microcontroller integrates a multi-channel a/d converter and PWM outputs 1 or 2 channels. Suspend and wake up function, oscillation type selection, features such as programmable divider, so that when the application requires only few external components.
With a/d converter with PWM, low power consumption, high performance, flexible input/output and lower costs, allowing the microcontroller can be applied with sensors and signal processing, motor controllers, industrial controls, consumer products and subsystems, and so . Most features of this series of them are generic, however, the main difference lies in the number of input/output pins, RAM and ROM, a/d resolution, the capacity of the stack layer and package types.
Features Working voltage:
fSYS=4MHz:2.2V ~5.5V
fSYS=8MHz:3.3V~5.5V
fSYS=12MHz:4.5V~5.5V 13 to 23 bi-directional input/output Shared with input/output pins for external interrupt input 8-bit programmable timer/counter overflow interrupt level 7
Prescaler Built-in Crystal or RC oscillator circuit Watchdog timer With PFD function can be used to voice Suspend and wake up function can reduce power consumption In vDD=5V, when the system frequency is 8MHz, instruction cycle is 0.5 μ s 4 or 6-level hardware stack 4-channel, 8-or 9-bit resolution a/d converter 1-or 2-channel 8-bit PWM output, shared with input/output pins Bit manipulation instructions Table look-up instructions 63 instructions Instructions instruction cycle time of 1 or 2 Low voltage reset function 100,000 erase/write Flash program memory 1,000,000 erase/write EEPROM data memory Flash program memory data validity > 10 EEPROM data validity > 10 ICP (In-Circuit Programming) interface Various case | Technology related information | Data Sheet Revision History Packaging information
16-pin NSOP package
18-pin DIP package
18-pin SOP package
20-Pin SSOP package
24-pin SKDIP packages
24-pin SOP package
24-Pin SSOP package
28-pin SKDIP packages
28-pin SOP package
28-pin SSOP package Support tools Software download Question-and-answer set Application examples | Other pertinent information | Product-related information
VORICE add HT46F46E, HT46F48E, HT46F49E industrial A/D-Flash microcontrollers (Flash MCU)
VORICE HT46F47E in A/D-new Flash MCU
Restricted products (HT46F46E) |
|
|
